BEONDT transport drone D300 can carry a maximum load of 300KG. It can transport construction materials as well as fruits, rice, corn and other crops.
Artikel-Nr :
D300Bestellung (MOQ) :
1Zahlung :
T/TProduktherkunft :
CHINAFarbe :
REDVerschiffungshafen :
SHANGHAIVorlaufzeit :
30DAYSThe 300 kg lifting drone is mainly used in emergency rescue and industrial transportation. It has multi-scenario adaptability and high load-bearing capacity. The following are the specific technical features:
Core performance
Maximum load: 300 kg, can carry ICU equipment, folding stretchers, mechanical arms and other medical equipment, or transport materials such as building materials and ore samples.
Multi-scenario adaptability
Complex terrain: Supports mountainous, urban canyon, disaster ruins and other scenes, equipped with Beidou navigation and binocular vision system to achieve millimeter-level obstacle avoidance.
Extreme weather: Protection level IP55, operating temperature range -20°C to 45°C, support rainstorm, dust and other environmental operations.
Power and safety
Power system: Adopt hybrid power (fuel + electric) or high energy density battery, combined with lightweight composite fuselage, to solve the contradiction between load and endurance.
Redundant design: Support 7 motor power redundancy to ensure safe flight in case of failure; dual-machine joint lifting technology can improve transportation efficiency and stability.
Application Cases
Emergency Transportation: Successfully transported a full set of ICU equipment and two medical staff to the disaster site in a 2025 actual combat exercise.
Industrial Transportation: Carried 50 kg of equipment to complete the maintenance of transmission towers during power inspections, increasing efficiency by 8 times compared to manual labor; Mining transportation shortened the geological exploration cycle by 40%.
Technical Parameters
Unfold the wheelbase |
5070mm |
Motor stator size |
1671*60.6mm |
Propeler size |
1620mm |
Fuselage unfolded dimension |
5970*5970*880mm |
Fuselage folded dimensions |
3650-3650*880mm |
Rated load |
250kg |
Maximum load |
≤300kg |
Maximum take-off weight |
620kg |
Bare metal self-weight |
180kg |
Battery weight |
140kg |
Flight altitude |
1-2km |
Maximum flight speed |
13m/s |
Flight distance |
1-2km |
Battery capacity |
18s 44000mAh |
Number of batteries |
8 |
Battery weight |
17.5kg |
Battery materials |
high-rate lithium battery |
Charging time |
30-40 minutes |
Operating voltage |
66v |
Charger power |
3000*8 |
Full load power |
88000w |
Recommended ambient temperature |
15~35℃ |
Propeller material |
Carbon |
Fuselage material |
Carbon fiber /aluminum alloy |
Payload (300kg) endurance |
10 minutes |
Payload (250kg) endurance |
12 minutes |
No-load (200kg) endurance |
14 minutes |
Number of camera axes |
2 axes |
Camera zoom factor |
10 times |
Camera resolution |
1080p 25fps |
Remote control screen resolution |
1080p |
Full load power |
880C0wresolution |
Positioning system |
GPS+dual-band RTK |
Positioning accuracy |
10-20cm |
FAQs
1. What is the approximate service life of a drone?
5-10 years, mainly depends on the user's maintenance of the drone.
2. How many flight hours?
Mainly, the battery needs to be replaced with a new one after 400-500 cycles of charging.
3. Which parts need to be replaced regularly?
Propellers, landing gear, water pumps, centrifugal nozzles, we recommend equipping each drone with 2 pairs.
4. What services does the drone need?
Clean the drone frequently and pay attention to whether the screws are loose and need to be replaced.
5. How long is the interval?
Mainly depends on the user's use. You should observe the condition of the drone frequently.
